MSI PRO H610M-S LGA1700 DDR5 Micro-ATX Motherboard

MSI PRO H610M-S LGA1700 DDR5 Micro-ATX Motherboard

The MSI PRO H610M-S DDR5 model is a Micro-ATX motherboard on the Intel H610 chipset for the LGA1700 socket, built for budget Intel systems that still want DDR5 memory. It supports Intel Core 14th, 13th and 12th Gen processors, plus Intel Pentium Gold and Celeron processors, making it a practical base for office PCs, study systems and everyday desktops.

Key Specifications

• Socket LGA1700 with Intel H610 chipset in a Micro-ATX form factor

• 2 DDR5 UDIMM slots supporting up to 128GB, with DDR5 speeds up to 5600 MT/s by JEDEC and POR, plus Intel XMP 3.0 support

• 1 PCIe 4.0 x16 slot and 1 PCIe 3.0 x1 slot

• 1 M.2 slot supporting PCIe 3.0 x4 for 2280, 2260 and 2242 devices, plus 2 SATA 6Gbps ports

• Realtek RTL8111H Gigabit LAN and Realtek ALC897 codec with 7.1-channel high definition audio

• HDMI 1.4 output with HDR supporting 4K at 30Hz, available only on processors featuring integrated graphics

• Rear USB: 2 USB 5Gbps Type-A ports and 4 USB 2.0 ports; front headers add 2 USB 5Gbps Type-A ports and 4 USB 2.0 ports

• 4 EZ Debug LEDs and TPM pin header supporting TPM 2.0

Frozr AI Cooling

Frozr AI Cooling detects CPU and GPU temperatures and automatically adjusts system fan duty to a proper value, keeping a compact budget build cool without constant manual tuning. Memory Boost delivers pure data signals for the best performance, stability and compatibility, Core Boost supports more cores through a premium layout and digital power design, and the Lightning Gen4 PCIe slot provides up to 64GB/s of bandwidth for a graphics card.

1. Pair a 12th, 13th or 14th Gen Intel Core processor with DDR5 memory up to 5600 MT/s.

2. Install a PCIe 4.0 graphics card for light gaming or keep the build on integrated graphics through HDMI.

3. Use the Gen3 M.2 slot for a fast boot drive and the two SATA ports for additional storage.
