Colorful CVN B560M GAMING FROZEN V20 LGA1200 DDR4 Micro-ATX Motherboard

Colorful CVN B560M GAMING FROZEN V20 LGA1200 DDR4 Micro-ATX Motherboard

The Colorful CVN B560M GAMING FROZEN V20 LGA1200 DDR4 Micro-ATX Motherboard is a white CVN board for 10th and 11th generation Intel Core processors on the LGA1200 socket, pairing DDR4 memory with PCIe 4.0 graphics and storage support. It suits builders reviving or extending an LGA1200 system in a compact case with a light-coloured theme.

Key Specifications

• Intel B560 chipset with LGA1200 socket for 10th and 11th generation Intel Core processors

• 4 DDR4 DIMM slots with dual-channel support, at DDR4 3200/3000/2933/2666/2400/2133MHz depending on the processor fitted

• 2 M.2 slots, with one PCIe 4.0 x4 slot and one PCIe 3.0 x4 slot with Intel Optane support, plus 6 SATA 3.0 6Gb/s ports

• 1 PCIe 4.0/3.0 x16 slot, 1 PCIe 3.0 x4 slot, and 1 PCIe 3.0 x1 slot

• HDMI and DisplayPort display outputs, Gigabit LAN, and 1 CNVi WiFi/BT module slot

• 8-channel high-definition audio codec, 2 5V 3-pin RGB headers, and 2 12V 4-pin RGB headers

• 128M UEFI BIOS in a 245mm x 245mm Micro-ATX layout

Full-Cover Cooling Fins with Extended VRM and PCH Heatsinks

Cooling uses full-cover cooling fins with an extended heatsink across the PCH and VRM, plus a snow-white PCB, so the board's white theme is matched by passive cooling that covers power delivery and the chipset. Steel-reinforced PCIe x16 slots, a pre-installed I/O shield, and 90-degree SATA ports round out a layout designed to stay tidy inside a smaller gaming case.

1. Choose a 10th or 11th generation Intel Core processor for the LGA1200 socket, noting that supported DDR4 speeds vary by processor generation and model.

2. Install DDR4 memory across the four slots in dual-channel configuration.

3. Place a PCIe 4.0 x4 SSD in the primary M.2 slot and a second SSD in the PCIe 3.0 x4 slot, adding SATA drives through the six SATA ports.

4. Fit a graphics card in the PCIe 4.0/3.0 x16 slot and add a WiFi/BT module through the CNVi slot where wireless connectivity is wanted.
