ASUS PRIME H610M-K ARGB LGA1700 DDR5 Micro-ATX Motherboard

ASUS PRIME H610M-K ARGB LGA1700 DDR5 Micro-ATX Motherboard

The ASUS PRIME H610M-K ARGB is a Micro-ATX DDR5 board on the Intel H610 chipset for LGA1700, giving 12th, 13th and 14th Gen Intel budget builds addressable RGB lighting, a PCIe 4.0 graphics slot and a simple upgrade path.

Key Specifications

• LGA1700 socket for Intel Core 14th, 13th and 12th Gen processors, plus Pentium Gold and Celeron processors, with Intel Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0 support

• Intel H610 chipset with 2 DDR5 DIMM slots, up to 96GB, and DDR5 speeds of 5600, 5400, 5200, 5000 and 4800MHz, with Intel XMP support

• 1 PCIe 4.0 x16 slot plus 1 PCIe 3.0 x1 slot

• 1 M.2 slot, type 2242/2260/2280, supporting PCIe 3.0 x4 mode, plus 4 SATA 6Gb/s ports

• Realtek 1Gb Ethernet, VGA and HDMI display outputs, with HDMI supporting 4K at 60Hz

• Rear USB: 2 USB 3.2 Gen 1 ports and 4 USB 2.0 ports, plus front headers for additional USB 3.2 Gen 1 and USB 2.0 ports

• Realtek 7.1 surround sound high definition audio codec with jack-detection, multi-streaming and front panel jack-retasking

Addressable RGB Lighting on a Budget H610 Board

The ARGB designation brings addressable RGB lighting to an otherwise entry-level H610 board, so a budget Intel build can still carry a coordinated lighting theme through Aura Sync-compatible components.

1. Install a 12th, 13th or 14th Gen Intel processor in the LGA1700 socket.

2. Fit two DDR5 modules for dual-channel memory up to 96GB.

3. Use the PCIe 4.0 x16 slot for a graphics card.

4. Install an NVMe SSD in the PCIe 3.0 M.2 slot and use the four SATA ports for additional storage.
